Containere
Dry Freight
20' Standard | 40' Standard | 40' High Cube | |
|---|---|---|---|
Maximum Gross Weight | 30,480 kg (67,200 lb.) | 30,480 kg (67,200 lb.) | 30,480 kg (67,200 lb.) |
Tare Weight | 2,200 kg ( 4,850 lb.) | 3,700 kg ( 8,168 lb.) | 3,890 kg ( 8,587 lb.) |
Payload | 28,280 kg (62,350 lb.) | 26,780 kg (59,032 lb.) | 26,590 kg (58,6133 lb.) |
External Dimensions | |||
Length | 6,058 mm (19'-10½") | 12,192 mm (40'-0") | 12,192 mm (40'-0") |
Width | 2,438 mm (8'-0") | 2,438 mm (8'-0") | 2,438 mm (8'-0") |
Height | 2,591 mm (8'-6") | 2,591 mm (8'-6") | 2,896 mm (9'-6") |
Internal Dimensions | |||
Length | 5,900 mm (19'-4¼") | 12,025 mm (39'-5½") | 12,025 mm (39'-5½") |
Width | 2,348 mm (7'-8½") | 2,348 mm (7'-8½") | 2,348 mm (7'-8½") |
Height | 2,385 mm (7'-9 7/8") | 2,385 mm (7'-9 7/8") | 2,690 mm (8'-9 7/8") |
Door Opening | |||
Width | 2,340 mm (7'-8 1/8") | 2,340 mm (7'-8 1/8") | 2,340 mm (7'-8 1/8") |
Height | 2,275 mm (7'-5 5/8") | 2,275 mm (7'-5 5/8") | 2,578 mm (8'-5½") |
Cube | |||
Cube Capacity | 33.04 m³ (1,166 ft.³) | 67.34 m³ (2,377 ft.³) | 75.95 m³ (2,681 ft.³) |
Test Loads | |||
Stacking | 97,200 kg (214,290 lb.) | 97,200 kg (214,290 lb.) | 97,200 kg (214,290 lb.) |
Transverse Racking | 15,240 kg ( 33,600 lb.) | 15,240 kg ( 33,600 lb.) | 15,240 kg ( 33,600 lb.) |
Longitudinal Racking | 7,620 kg ( 16,800 lb.) | 7,620 kg ( 16,800 lb.) | 7,620 kg ( 16,800 lb.) |
Floor Strength | 7,260 kg ( 16,000 lb.) | 7,260 kg ( 16,000 lb.) | 7,260 kg ( 16,000 lb.) |
